1200kW 1000RPM CNPC Jichai Gas Generator Set
Bore*Stroke(mm): 200*255 Displacement: 96.1L Aspiration: Turbocharger Control: Electronic Speed Governing Rated Speed: 1000RPM Rated Power(prime): 1200kW
| U1GJ1200-G Gas Generating Set Features | |
| Voltage Regulation | Features accurate voltage regulation for stable power output. |
| Dynamic Performance | Excellent dynamic performance with minimal voltage waveform distortion. |
| Efficiency | High efficiency, ensuring optimal energy usage. |
| Structure | Compact design that saves space and is easy to install. |
| Maintenance | Easy to maintain, reducing downtime and maintenance costs. |
| Speed | Low-speed operation for extended engine life and reduced wear. |
| Reliability | Known for reliable performance and long operational lifespan. |
| Cost-Effective | Designed to offer excellent value for money, making it a cost-effective solution. |
| Versatility | Can either transfer electricity directly to load or be combined with two or more sets in a power station. |
| Applications | Suitable for use as both normal and stand-by power in various industries such as oil fields, factories, and resource development bases. |
| Engine Design | -Designed by AVL, Austria -Intellectual Property belong to Jichai - Triaxiality Finite Element Analysis - Longer Stroke, More displacement - Low Speed (1000RPM), More Reliable - Advanced World Standard Performance |
| Alternator | - Brushless Excitation - AVR - Better Insulation and Protection |
| Safety | - Low Oil Pressure Auto Stop Protection - Over Speed Auto Stop Protection - Explosion Proof - High Coolant Temerature Alarm - Low Coolant Level Alarm - High Oil Temperature Alarm - Emergency Stop Device - Complete Electrical Protection |
| Testing | - Strict Inspection and Factory Test for Each Gen-set - Start Performance Test - Load Test - Synchronization Test - Safety System Test |
| The Whole Equipment Supply | - Standard Scope of Supply - Optional Equipment List - Repairing Tools - Spare Parts - Meet the Requirement for All Accessories of Project |
| Technical Support & Services | - Free Technical Support and Training Service - 24/7 Technical Service Tel Number - Rapid Spare Parts Supply - After Sales Service for Generator Set Lifetime |
| Property Parameters: | |
| Model | U1GJ1200-G |
| Engine Type | Jichai L12V200ZLT-2 |
| Alternator Type | 1FC Series (SIEMENS Technology) |
| Rated Power | 1200kW |
| Rated Speed | 1000RPM |
| Rated Frequency | 50Hz |
| Rated Voltage | 6.3kV |
| Rated Power Factor | 0.8 |
| Electrical Efficiency | ≥38.7% |
| Cooling Method | Inter-cooling, with Horizontal Radiator |
| Emergency Genset Function | Automatic Device |
| Control Module | Deepsea DSE8610 |
| Weight | 20,600kg |
| Dimension | 7500*2300*2800mm |
*Rating and fuel consumption based on ISO Standard conditions (Ambient temperature at 25 degree Centigrade, Atmospheric pressure at 100kPa and Relative humidity at 30%). Site rating and fuel consumption should amend according to relative standard.
| Main Specification of Engine: | |
| Model of Engine | Jichai L12V200ZLT-2 |
| Rated Power(kW) | 1200 |
| Rated Speed(r/min) | 1000 |
| No. and Layout of cylinders | 12-cylinder, 60°Vee |
| Type | Four Strokes, V Type, Turbocharged Inter-cooling, Spark Plug Ignition |
| Bore(mm) | 200 |
| Stroke(mm) | 255 |
| Total Displacement(L) | 96.1 |
| Specific Oil Consumption(g/kW.h) | ≤0.6 |
| Idle Speed(r/min) | 700 |
| Gas Pressure(kPa) | 100~400 |
| Heat Rate(kJ/kW.h) | ≤8850 |
| Exhaust Temperature(Before Turbocharger. ℃） | ≤650 |
| Water Outlet Temperature(℃) | ≤85 |
| Water Inlet Temperature of Inter-cooler(℃) | ≤45 |
| Lube Temperature(℃) | ≤90 |
| Main Specification of Alternator | |
| Model of Alternator | 1FC series (SIEMENS technology) |
| Rated Power(kW) | 1000 |
| Rated Power Factor(cosΦ) | 0.8 |
| Rated Voltage(V) | 6.3kV |
| Rated Speed | 1000RPM |
| Rated Frequency(Hz) | 50 |
| Exciting Method | Brushless |
| Wiring Method | 3 phase 4 wire, Y type connection |
| Insulation Class | F |
| Class of Protection | IP23 |
| Cooling | A fan at the drive end draws the cooling air |
| Bearing Structure | Duplex bearing |
| Direction of Rotation | Clockwise (facing to generator drive end) |
